The LTM4615EV is A full 4A dual-output switching mode DC/DC power supply with an additional 1.5A VLDO (very low voltage differential) linear regulator. Built into the package are the switching controller, power FETs, inductors, a 1.5A regulator and all supporting components.

Additional features of the device include overvoltage protection, reentry overcurrent protection, thermal shutdown, and programmable soft start.

Features:

Dual 4A output power supply with 1.5V VLDO™

Short circuit and overheat protection

Power good indicator

Switching Regulator section - current mode control

Input voltage range: 2.375V to 5.5V

Each channel can provide 4A DC (typical value), 5A peak output current

Each channel can provide output from 0.8V to up to 5V and can be paralleled

±2% total DC output error

Output voltage tracking

Up to 95% efficiency

Programmable soft start

VLDO part

VLDO, 1.14V to 3.5V input range

VLDO, 0.4V to 2.6V, 1.5A output

VLDO, 40dB power suppression (at fSW)

±1% total DC output error

Compact and very flat package: 15mm x 15mm x 2.82mm

Applications:

Telecommunications and network equipment

Industrial power system

Low noise application

FPGA and SERDES power supplies
