S25FS512SAGNFA013 is NOR Flash Memory IC,offer high densities coupled with the flexibility and fast performance required by avariety of mobile or embedded applications.

Product Attributes Of S25FS512SAGNFA013

Memory Size：512 Mbit

Supply Voltage - Min：1.7 V

Supply Voltage - Max：2 V

Active Read Current - Max：60 mA

Interface Type：SPI

Maximum Clock Frequency：133 MHz

Organisation：64 M x 8

Data Bus Width：8 bit

Timing Type：Synchronous

Minimum Operating Temperature：- 40 C

Maximum Operating Temperature：+ 85 C

Speed：133 MHz

Features Of S25FS512SAGNFA013

Serial peripheral interface (SPI) with multi-I/0

SPI clock polarity and phase modes 0 and 3

Double data rate (DDR) option

Extended addressing: 24- or 32- bit address options

Commands: Normal, Fast, Dual I/O, Quad /O, DDR Quad I/0

Modes: Burst wrap, continuous (XIP), QPI

Serial flash discoverable parameters (SFDP) and common flash interface (CFI) for configuration information

256 or 512 bytes page programming buffer

Program suspend and resume

Automatic error checking and correction (ECC) - Internal hardware ECC with single bit error correction
