108-1511-200 -- Paladin® 112Gb/s Backplane Connector, 5-Pair, Guide Module, No Key.

Overview:

The Paladin®112Gb/s backplane interconnect system features breakthrough technology that enables customers to design complex systems to support today's data rates, with room for upgrades for future performance requirements. This series of connectors has a smooth linear transmission bandwidth of more than 40GHz, very low crosstalk, and consistent signal integrity across the entire range of adapter products.

Advantages

The impedance range is ± 5 ohms

At 25GHz, the difference between insertion loss (IL) and crosstalk (XT) exceeds 40dB

Signal contacts do not generate stump resonance

Best-in-class crosstalk and common-mode conversion performance with 40GHz bandwidth

The low time delay design can avoid the wiring problem of the board end coupling architecture

When the connector unplugged length reaches 2 mm, the impedance change is less than 5 ohms

Extensive product range, supporting traditional backplane, direct orthogonal, cable, coplanar and parallel card applications

Double-track wiring can reduce the number of layers of the board and reduce the system cost
