170335-3607 is a high-performance, high-speed backplane connector belonging to the Impact™ series. This connector is designed for high-density, high-speed data transmission applications and is widely used in communications, data centres, and industrial automation fields.

170335-3607 Features

High-density design: 192 circuits, supporting high-density connections.

High-Speed Transmission: Supports data transfer rates of up to 25.0 Gbps.

Low Impedance: 85Ω characteristic impedance ensures signal integrity.

High Reliability: Durable for up to 200 mating cycles.

Multiple Applications: Suitable for backplane connections and mezzanine applications.

170335-3607 Specifications

Number of Circuits: 192 circuits

Colour: Grey

Materials:

Metal: High-performance alloy (HPA)

Joint plating: Gold

Terminal plating: Tin

Resin: High-temperature thermoplastic

Dimensions:

Number of columns: 6

Number of rows: 12

PCB solder pad length: 1.40 mm

Pitch: 1.35 mm and 1.90 mm

Electrical parameters:

Maximum current per contact: 0.75 A

Maximum voltage: 30V AC (RMS)/DC

Operating temperature range: -55°C to +85°C

Package type: Through-hole

170335-3607 Application Scope

Communication equipment: Used in switches, routers, and other high-speed data transmission devices.

Data centres: Suitable for backplane connections in servers and storage devices.

Industrial automation: Used in industrial equipment requiring high-reliability connections.
