The BTS6305UJ is a broadband, high linearity pre-driver amplifier for 5G mMIMO infrastructure applications with fast switching to support TDD systems. The amplifier is designed to operate from 2.4 GHz to 4.2 GHz and is available in a 3 mm × 3 mm × 0.85 mm 16-terminal HVQFN package.

The amplifier is ESD protected on all terminals.

Features

High saturation output power Po(sat) = 29 dBm

High power gain Gp = 38 dB

High linearity performance ACLR = -44 dBc

Unconditional stabilisation

Supports fast switching of TDD systems

5 V single supply with 80 mA quiescent current

Small 16-solder end pinless package 3 mm x 3 mm x 0.85 mm

ESD protection on all pins

Humidity sensitivity class 1

Applications

Communications infrastructure

TDD systems

Wireless infrastructure 5G NR mMIMO

High linearity pre-driver amplifiers
