The ADSP-21477BCPZ-1A offers an ultra-low power, high-performance processor - 200 MHz/1200 MFLOP in an 88-pin LFCSP package. The ADSP-21477's low-power architecture makes these products ideally suited for applications in the automotive audio and industrial control markets that require low power consumption.

Features

200 MHz core clock speed

2 Mb of on-chip RAM

FIR, IIR and FFT accelerators

Digital Application Interface (DAI) enables user-customised access to peripherals, including an S/P DIF Tx/Rx and an 8-channel asynchronous sample rate converter.

Fully enhanced DMA engine including scatter/aggregate DMA, delay line DMA

8 serial ports (SPORT) supporting I2S, left-aligned sample pairs and TDM modes

Watchdog timer

Shift registers

2 SPI-compatible ports supporting master and slave modes

UART and two-wire interfaces

16 Pulse Width Modulation (PWM) channels

3 full-function timers

ADSP-21477BCPZ-1A Product Attributes:

Category: Embedded DSP (Digital Signal Processor)

Family: SHARC®

Package: Tray

Part Status: On Sale

Type: Floating Point

Interface: DAI, DPI, I2C, SPI, SPORT, UART/USART

Clock Rate: 200MHz

On-Chip RAM: 2Mb

Voltage - I/O: 3.30V

Voltage - Core: 1.20V

Operating Temperature: -40°C ~ 85°C (TA)

Mounting Type: Surface Mount

Package/Shell: 88-VFQFN Exposed Pad, CSP

Supplier Device Package: 88-LFCSP-VQ (12x12)

Base Product Number: ADSP-21477
