STM32WB5MMGH6TR - Bluetooth® Low Energy 5.3 and 802.15.4 Module

Part Number: STM32WB5MMGH6TR

Package: 86-LFLGA Module

Type: Bluetooth Module

Description: Multiprotocol Modules - Bluetooth v5.0, Thread, Zigbee® Transceiver Module 2.4GHz

Product Overviews

STM32WB5MMGH6TR is an ultra-low-power and small form factor certified 2.4 GHz wireless module. It supports Bluetooth® Low Energy 5.3, Zigbee® 3.0, OpenThread, dynamic and static concurrent modes, and 802.15.4 proprietary protocols. Its low-power features enable extended battery life time, small coin-cell batteries or energy harvesting.

Product Features

• Include ST state-of-the-art patented technology

• Integrated chip antenna

• Bluetooth® Low Energy 5.3, Zigbee® 3.0, OpenThread certified

• Dynamic and static concurrent modes

• IEEE 802.15.4-2011 MAC PHY

• Supports 2 Mbits/s

• Frequency band 2402-2480 MHz

• Advertising extension

• Tx output power up to +6 dBm

• Rx sensitivity: -96 dBm (Bluetooth® Low Energy at 1 Mbps), -100 dBm (802.15.4)

• Range: up to 75 meters

• 1-Mbyte Flash memory, 256-Kbyte SRAM

• Fully integrated BOM, including 32 MHz radio and 32 KHz RTC crystals

• Integrated SMPS

• Ultra-low-power modes for battery longevity

• 1.71 V to 3.6 V VDD range

• -40 °C to 85 °C temperature range

Applications

• Lighting and home automation

• Wireless audio devices

• Wellness, healthcare, personal trackers

• Gaming and toys

• Smart locks
