DP83TC813RRHFTQ1 device is an IEEE 802.3bw compliant automotive PHYTER™ Ethernet physical layer transceiver which can work with Unshielded Twisted Pair cable.

Features

Open Alliance and IEEE 802.3bw 100BASE-T1 compliant

Passes Level IV emissions with Integrated LPF

TC-10 compliant with < 20μA sleep current

Small Form Factor: 28pin VQFN (5mm x 4mm)

SAE J2962-3 EMC compliant

Configurable /0 voltages: 3.3 V, 2.5V, and 1.8 V

MAC interfaces: MII, RMII, RGMII and SGMII

Optional separate voltage rail for MAC interface pins (3.3V, 2.5V, 1.8 V)

AEC-Q100 qualified for automotive applications:

Temperature grade 1:- -40°C to +125 °C  ambient operating temperature

+8-KV HBM ESD for pins 19 and 20

IEC61000-4-2 ESD classification level 4 for pins 19 and 20: +8-kV contact discharge

IEEE 1588 SFD support

TSN compliant with 802 .3br frame pre-emption support

Low active power operation: < 230 mW

Diagnostic tool kit

Signal quality indication (SQI)

Time domain reflectometry (TDR)

Electrostatic discharge sensor

Voltage sensor

PRBS Builtin Self-Test

Loopbacks

VQFN, wettable flank packaging

Applications

ADAS

Gateway and Body Control

Telematics
