VSC7428XJG-12 Ethernet switches is pin-compatible devices and provide port counts ranging from 11 Ethernet ports to 26 Ethernet ports. Up to 12 ports include a Gigabit copper PHY, and the remaining ports provide single and quad SGMII (QSGMII) and SerDes interfaces. Up to two ports can run at 2.5 Gbps. These devices provide a rich set of Carrier Ethernet switching features such as queue-based Ethernet services, provider bridging, protection switching, and synchronous Ethernet.

General Features

All 1G Ethernet ports are tri-speed 10/100/1000 Mbps ports

All 2.5G Ethernet ports are quad-speed 10/100/1000/2500 Mbps ports

Integrated copper transceivers are compliant with IEEE 802.3ab and support Microsemi ActiPHY™ link down power savings and PerfectReach™ smart cable reach algorithm

SGMII ports support both 100-BASE-FX and 1000-BASE-X-SERDES

Four megabits of integrated shared packet memory

Fully nonblocking wire-speed switching performance for all frame sizes

Eight priorities and eight queues per port

Dual leaky bucket policing per queue and per port

DWRR scheduler/shaper per queue and per port with a mix of strict and weighted queues

256 TCAM-based egress tagging entries

Up to 256 TCAM-based classification entries for Quality of Service (QoS) and VLAN membership

Up to 512 host identity entries for source IP guarding

256 TCAM-based security enforcement entries
