The MC35FS6503CAE is a multi-output, power supply, integrated circuit including a CAN Flexible Data (FD) transceiver dedicated to the harsh automotive and transport markets requiring high reliability (Class 0) and high availability. A variety of switching and linear regulators are available, including a low power mode (32 μA) and various wake-up functions. Advanced power management schemes enable high efficiency over a wide input voltage range (down to 2.7 V) and output current range.

Function

● Battery voltage detection and MUX output pins

● Highly flexible SMPS pre-regulator that allows for two topologies: non-inverting buck-boost

● Highly flexible SMPS pre-regulator allows two topologies: non-inverting buck-boost and standard buck

● 36 V maximum input operating voltage

● 1.0 V to 5.0 V or LDO (0.5 A) for MCU cores via SMPS (0.8 A or 1.5 A) or LDO (0.5 A)

● Linear regulator dedicated to auxiliary functions or sensor supply (VCCA or standalone), 5.0 V or 3.3 V

● 3.3 V holding memory supply in low-power mode

● Long duration timer with counts up to 6 months and 1.0 second resolution

● Multiple wake-up sources in low-power mode: CAN, IO, LDT

● Five configurable I/Os

Applications

● TA up to 150 °C, TJ up to 175 °C

● Drivetrain electrification (BMS, hybrid electric and hybrid electric vehicles, inverters, DCDC, AC starters)

● Drivetrain - Chassis and Safety (active suspension, steering, safety domain gateway)

● Drivetrain (EMS, TCU, Transmission)
