MC33FS8430G1ES - Fail-safe system basis chip with multiple SMPS and LDO

Product Description

MC33FS8430G1ES is an automotive functionally safe multi-output power supply integrated circuit, with focus on Radar, Vision, ADAS domain controller, Radio and Infotainment applications. It includes multiple switch mode and linear voltage regulators. It offers external frequency synchronization input and output, for optimized system EMC performance.

Features and Benefits

60V DC maximum input voltage for 12 V and 24 V applications

VPRE synchronous buck controller with external MOSFETs. Configurable output voltage, switching frequency, and current capability up to 10 A peak.

BOOST converter with integrated low-side switch. Configurable output voltage and max input current up to 1.5 A peak.

EMC optimization techniques including SMPS frequency synchronization, spread spectrum, slew rate control, manual frequency tuning

2x linear voltage regulators for MCU IOs and ADC supply, external physical layer. Configurable output voltage and current capability up to 400 mA DC.

OFF mode (power down) with very low quiescent current (10 µA typ)

2x input pins for wake-up detection and battery voltage sensing

Device control via 32 bits SPI or I2C interface with CRC

Applications

Radar (corner radar, imaging radar, ...)

Vision (mono camera, stereo camera, night vision, ...)

ADAS domain controller

Infotainment
