AD8220WARMZ is the first single-supply, JFET input instrumentation amplifier available in an MSOP package. The AD8220 can operate on a ±18 V dual supply, as well as on a single +5 V supply. Its railto-rail output stage maximizes dynamic range on the low voltage supplies common in portable applications.

Product Features

Low input currents

10 pA maximum input bias current (B grade)

0.6 pA maximum input offset current (B grade)

High CMRR

100 dB CMRR (minimum), G = 10 (B grade)

80 dB CMRR (minimum) to 5 kHz, G = 1 (B grade)

Excellent ac specifications and low power

1.5 MHz bandwidth (G = 1)

14 nV/√Hz input noise (1 kHz)

Slew rate: 2 V/μs

750 μA quiescent supply current (maximum)

Versatile

MSOP package

Rail-to-rail output

Input voltage range to below negative supply rail

4 kV ESD protection

4.5 V to 36 V single supply

±2.25 V to ±18 V dual supply

Gain set with single resistor (G = 1 to 1000)

Applications

Medical instrumentation

Precision data acquisition

Transducer interfaces
