The AM2631CNDGHAZCZR microcontroller is designed to meet the complex real-time processing needs of next-generation industrial and automotive embedded products. Includes multiple pin-to-pin compatible devices with up to four 400MHz Arm® Cortex®-R5F cores. Optionally, the Arm® R5F subsystem can be programmed to operate in lockstep or dual-core mode, allowing for multiple functionally safe configurations. The Industrial Communications Subsystem (PRU-ICSS) supports integrated industrial Ethernet communication protocols, standard Ethernet connectivity, and custom I/O interfaces.

Product Attributes

Core processor: ARM® Cortex®-R5F

Core specification: 32-bit single core.

Speed: 400 MHz

Connectivity: CANbus, Ethernet, I2C, MMC/SDIO, QSPI, SPI, UART/USART

Peripherals: AES, DMA, POR, PWM, SHA, TRNG, WDT

Number of inputs/outputs: 140

Program memory capacity 256KB (256K x 8)

Program memory type: Tightly coupled memory (TCM)

RAM size: 2M x 8

Supply Voltage (Vcc/Vdd): 1.14V ~ 1.26V 1.14V ~ 1.26V

Data Converter: A/D 6x12b SAR; D/A 1x12b

Oscillator Type: Built-in

Operating Temperature: -40°C ~ 105°C (TJ)

Mounting Type: Surface Mount

Package/case: 324-LFBGA

Scope of delivery: 324-NFBGA (15x15)

Applications

● Single- and multi-axis servo drives

● AC inverters and VF drives

● Solar energy

● Electric vehicle charging

● Renewable energy storage

● Traction inverters

● In-vehicle chargers

● DC-DC converters

● Battery management systems

● Combiner Box Architecture

● IO aggregators

● Domain controllers
