The CC3120R device is part of the SimpleLink™ microcontroller (MCU) platform, which includes Wi-Fi®, low-power Bluetooth®, Sub-1GHz devices and a host MCU, all sharing a common, easy-to-use development environment with a single-core software development kit (SDK) and a rich set of tools. With a single integrated SimpleLink™ platform, any combination of devices from the portfolio can be added to your design, enabling 100% code reuse when design requirements change.

Connect any microcontroller (MCU) to the Internet of Things (IoT) with the CC3120R device from Texas Instruments (TI)™. The Wi-Fi Alliance® certified CC3120R devices are part of the second generation SimpleLink™ Wi-Fi® family of solutions, greatly simplifying the implementation of low-power Internet connectivity. The CC3120R supports all Wi-Fi and Internet protocols implemented in ROM and runs on a dedicated on-chip Arm® network processor, greatly reducing the strain on the host MCU and simplifying system integration.

The CC3120R Wi-Fi® Internet-on-a chip™ device contains a dedicated Arm® MCU, reducing much of the networking activity of the host MCU. The subsystem includes an 802.11b/g/n radio, baseband and MAC with a powerful encryption engine that uses 256-bit encryption for fast, secure Internet connectivity.

The CC3120R device supports base station, access point and Wi-Fi Direct modes. The device also supports WPA2™ Personal and Enterprise security as well as WPA3™ Personal and Enterprise. The device includes embedded TCP/IP and TLS/SSL stacks, HTTP servers and multiple Internet protocols. The CC3120R device supports a variety of Wi-Fi configuration methods including Access Point Mode based HTTP, SmartConfig™ technology and WPS2.0.

Product attributes

Family SimpleLink™

Type TxRx + MCU

RF family/standard WiFi

Protocol 802.11b/g/n

Modulation DSSS, OFDM

Frequency 2.4GHz

Data Rate (Max) 54Mbps

Power - Output 18dBm

Sensitivity - 96dBm

Storage Capacity -

Serial Interface SPI, UART

Voltage - Supply 2.1V ~ 3.6V

Current - Receive 59mA

Current - Transmit 229mA

Operating Temperature -40°C ~ 85°C

Mounting Type Surface Mount

Package/Case 64-VFQFN Exposed Pad

Supplier Device Package 64-VQFN (9x9)

Applications

- For Internet of Things applications (IoT) such as

- Cloud connectivity

- Internet gateways

- Home and building automation

- Electrical appliances

- Access control

- Security Systems

- Smart Energy

- Industrial Controls

- Smart Socket and Meter Metering

- Wireless Audio

- IP Network Sensor Nodes

- Asset Tracking

- Medical Devices
