The SKY66421-11 is a high-performance, highly integrated RF front-end module designed for LPWAN (supporting LoRa®, SigFox, and other unlicensed band technologies) and high-power industrial, scientific, and medical (ISM) applications operating in the 860-930 MHz frequency range.

With fully matched 50ΩTX (or TX_ALT) and RX inputs and antenna outputs, and digital controls compatible with 1.6 to 3.6V CMOS levels, the SKY66421-11 is easy to use with maximum flexibility.

Features:

Integrated PA with +27 dBm output power

Integrated receive bypass path

Alternate Tx input pins simplify connection to any SoC

Very low RX bypass insertion loss: 0.6 dB (typical)

Single-ended 50 transmit/receive RF interface

Fast opening/closing time: <1μsec

Supply voltage: 2.0 to 4.8V

Low gain power amplifier

Sleep mode current: <1μA

MCM (16-pin, 3.0 X 3.0 X 0.75 mm) NiPdAu electroplated Package (MSL3, 260 C, according to JEDEC J-STD-020)

Applications:

LP-WAN device

Internet of Things

Smart meter

Industrial application

Range extender
