The R5F565NCHGFB 32-bit general-purpose microcontroller is ideally suited for IoT devices that require enhanced security, connectivity and HMI. The microcontrollers have built-in high-capacity flash memory and RAM and are available in a variety of packages for a wide range of applications.

Product Attributes

Core Processor: RXv2

Core specification: 32-bit single core

Speed: 120MHz

Connectivity: CANbus, EBI/EMI, Ethernet, I²C, LINbus, MMC/SD, QSPI, SCI, SPI, UART/USART, USB

Peripherals: DMA, LVD, POR, PWM, WDT

Number of I/O: 111

Program memory capacity: 1.5MB (1.5M x 8)

Programme memory type: Flash

EEPROM Size: 32K x 8

RAM Size: 640K x 8

Voltage - Supply (Vcc/Vdd): 2.7V ~ 3.6V

Data Converter: A/D 29x12b; D/A 2x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Package/Case: 144-LQFP

Supplier Device Package: 144-LFQFP (20x20)
