The R7FS5D37A3A01CFP microcontroller features a high-performance Arm Cortex®-M4 core running at up to 120 MHz.This MCU is best suited for applications that require a high-performance Cortex M4F core and do not require on-chip graphics acceleration or Ethernet connectivity.

Product Attributes

Product Category: ARM Microcontrollers - MCUs

Family: S5D3

Mounting Style: SMD/SMT

Package / Case: LQFP-100

Core: ARM Cortex M4

Programme memory size: 512 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 120 MHz

Number of inputs/outputs: 76 I/Os

Data RAM size: 256 kB

Supply voltage - min: 2.7 V

Supply voltage - max: 3.6 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 105 C

DAC resolution: 12 bit

Data Ram Type: SRAM

Development Kit: YSTBS5D3E10

Height: 1.7 mm

Interface Type: CAN, I2C, IrDA, QSPI, SCI, SDHI, SPI, SSIE, USB

Length: 14 mm

Humidity Sensitivity: Yes

Number of ADC channels: 19 Channel

Number of Timers/Counters: 13 Timer

Processor Family: SD53

Product: MCU+DSP+FPUs

Product Type: ARM Microcontrollers - MCUs

Programme Memory Type: Flash

Factory Package Quantity: 90

Sub Category: Microcontrollers - MCUs

Trade Name: Synergy

Watchdog Timer: Watchdog Timer

Width: 14 mm

Unit weight: 600 mg
