CYPD8125-48LDXI is the single port 48-QFN tray packing option of EZ-PD™ CCG8 family of USB-C port controllers. It complies with the latest USB -C and Power Delivery (PD) specifications.

Summary of Features

USB Type-C and Power Delivery 3.1 with EPR up to 28V supporting USB3 and USB4, Thunderbolt, DisplayPort Alternate Mode platforms

32-bit, 48 MHz Arm® Cortex®-M0 Plus processor with integrating a complete Type-C transceiver including the Type-C termination resistors Rp, Rd, and dead battery Rd termination

Integrated load switch controller for driving NFETs on VBUS provider path

Slew rate controller turn-on the VBUS provider path

Configurable hardware-controlled VBUS overvoltage, undervoltage, overcurrent, short circuit, reverse current protection, and thermal shutdown

VBUS high-side current sense amplifier capable of measuring current across 5-m series resistance on the provider path

Integrated 3:1 SBU Muxes for Alternate modes and closed chasis debug

Integrated digital blocks

Four timers, counters, PWMs, and up to 23 GPIOs

Four SCBs for configurable master/slave I²C, SPI or UART

Package: 48-QFN (6x6 mm)

Potential Applications

Notebooks and desktops

Thunderbolt hosts, non-Thunderbolt hosts
