The UCC5390ECQDWVRQ1 is a single-channel isolated gate driver with 10A peak pull current and 10A peak fill current designed to drive MOSFETs, IGBTs and SiC MOSFETs. The UCC5390-Q1's UVLO2 is based on GND2, which facilitates the use of bipolar power supplies and optimizes SiC and IGBT switching behavior and robustness. The device is ideal for on-board chargers, traction inverters for electric vehicles and DC charging stations.

Specifications

Technology: capacitive coupling

Number of channels: 1

Voltage - isolation: 5000Vrms

Common-mode transient immunity (min) : 120kV/µs

Propagation delay tpLH/tpHL (maximum) : 60ns, 60ns

Pulse width distortion (Max) : 20ns

Rise/fall time (typical value) : 10ns, 10ns

Current - Output high, low: 17A, 17A

Current - Peak output: 10A

Voltage - Forward (Vf) (typical value) : -

Voltage output power supply: 13.2V ~ 33V

Class: Automobile class

Qualification: AEC-Q100

Operating temperature: -40°C ~ 150°C

Mounting type: Surface mount type

Package/housing: 8-SOIC (0.295", 7.50mm wide)

Supplier device package: 8-SOIC

Certification body: CQC, UL, VDE

Basic product number: UCC5390
