The nRF52811 Bluetooth® 5.2 Direction Finding SoC takes full advantage of the latest and most powerful features of Bluetooth 5.2. These features include direction finding, which takes Bluetooth positioning to a new level. The devices are powered by a 64MHz Arm® Cortex™-M4 CPU. The devices are equipped with a variety of digital peripherals including PDM, PWM, UART, SPI and TWI. nRF52811 also features a powerful 12-bit ADC. The devices use an advanced on-chip adaptive power management system to achieve extremely low power consumption.

The radio in the nRF52811 SoC has comprehensive protocol capabilities, including Bluetooth® 5.2 direction finding, all Bluetooth® 5.2 features, 802.15.4, Thread, Zigbe, ANT and 2.4GHz proprietary protocols. With 4dBm TX power, the device is optimised to provide optimal RX sensitivity for all SoCs in the nRF52 family:

- Bluetooth Low Power - Long Range: -104dBm

- Bluetooth Low Power - 1Mbps: -97dBm

- 802.15.4 (Thread/Zigbee): -101dBm

Specification

Product Type: RF System-on-Chip - SoC

Type: Bluetooth

Core: ARM Cortex M4

Operating frequency: 2.4 GHz

Maximum data rate: 2 Mbps

Output power: 4 dBm

Sensitivity: - 96 dBm

Supply voltage - min: 1.7 V

Supply voltage - maximum: 3.6 V

Receive supply current: 4.6 mA

Transfer supply current: 4.6 mA

Program memory size: 192 kB

Min. operating temperature: - 40 C

Max. operating temperature: + 85 C

Package / Case: QFN-48

ADC resolution: 12 bit

Data bus width: 32 bit

Data RAM size: 24 kB

Data Ram type: RAM

Interface types: PDM, PWM, SPI, UART, TWI

Length: 6 mm

Max. clock frequency: 64 MHz

Humidity sensitivity: Yes

Mounting style: SMD/SMT

Number of inputs/outputs: 32 I/O

Program memory type: Flash

Series: NRF52811

Factory Pack Quantity: 3000

Technology: Si

Width: 6 mm

Unit weight: 505.850 mg

Applications

Beacons

Network processors

Proximity solutions

Real-time positioning systems

Asset Tracking

Smart Home
