The S9KEAZN64AMLCR 32-bit microcontrollers are cost-effective ARM®-based solutions for a wide range of automotive applications and are pin-compatible with the Kinetis EA family and future Kinetis automotive product families. The family includes a suite of analogue, communication, timing and control peripherals with different flash sizes and pin counts. These scalable devices are very robust and have strong ESD/EMC performance for cost-sensitive automotive applications. The family is supported by several development tools and reference hardware and software to help users get their designs off the ground quickly.

Product Attributes

Core Processor: ARM® Cortex®-M0+

Core specification: 32-bit single core

Speed: 40MHz

Connectivity: I²C, LINbus, SPI, UART/USART

Peripherals: LVD, POR, PWM, WDT

Number of I/O: 28

Program memory capacity: 64KB (64K x 8)

Program memory type: Flash

EEPROM Size: 256 x 8

RAM Size: 4K x 8

Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V

Data Converter: A/D 16x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Case: 32-LQFP

Supplier Device Package: 32-TQFP (7x7)

Applications

● Infotainment connectivity modules

● Parking assistance

● DC/DC motor control

● Electronic parking brake

● TPMS

● Motorcycle CDI/EFI

● Battery Management

● Pump/Fan Controller

● Passive Push Button Start
