The STM32F072CBT6 is a high-performance 32-bit ARM Cortex-M0 microcontroller (MCU) in an LQFP-48 package, suitable for embedded applications such as industrial control, consumer electronics, and automotive electronics.

STM32F072CBT6 Product Features

High-performance 32-bit RISC architecture:

48 MHz clock speed, achieving up to 48 MIPS (million instructions per second).

Three-stage pipeline for enhanced instruction execution efficiency.

Extended instruction set supporting complex operations.

Large memory resources:

128 KB Flash program memory (supporting 100,000 erase/write cycles with data retention for 20 years).

16KB SRAM for runtime data caching.

CRC calculation unit for enhanced data verification capabilities.

Rich peripheral interfaces:

12-bit ADC (16 channels) for multi-channel analogue signal acquisition.

12-bit DAC (2 channels) for analogue signal output.

2×I2C, 2×SPI/I2S, 4×USART for support of multiple serial communication protocols.

USB full-speed device interface (crystal-less design) simplifies circuit design.

CAN 2.0B controller for automotive and industrial communication.

7×16-bit timers + 1×32-bit timer supporting PWM output.

Low-power design:

Operating voltage range: 2.0V to 3.6V, suitable for various power supply environments.

Multiple low-power modes (sleep, stop, standby) for battery-powered devices.

High reliability design:

Independent watchdog (IWDG) to prevent system lockups.

Clock safety system (CSS) detects clock faults and automatically switches to a backup clock.

5V fault-tolerant I/O enhances EMC performance.

STM32F072CBT6 Product Attributes

Manufacturer: STMicroelectronics

Product Type: ARM Microcontroller - MCU

Series: STM32F072CB

Mounting Style:    SMD/SMT

Package/Case:    LQFP-48

Core:    ARM Cortex M0

Program Memory Size:    128 kB

Data Bus Width:    32 bit

ADC Resolution:    12 bit

Maximum Clock Frequency:    48 MHz

Number of I/O Pins:    37 I/O

Data RAM Size:    16 kB

Supply Voltage - Minimum:    2 V

Supply Voltage - Maximum:    3.6 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C
