ADS131M08IPBSR is a eight-channel, simultaneouslysampling, 24-bit, delta-sigma (ΔΣ), analog-to-digital converter (ADC) that offers wide dynamic range, low power, and energy-measurement-specific features, making the device an excellent fit for energy metering, power metrology, and circuit breaker applications.

Product Features

8 simultaneously sampling differential inputs

Programmable data rate up to 32 kSPS

Programmable gain up to 128

Noise performance:

– 102-dB dynamic range at gain = 1, 4 kSPS

– 80-dB dynamic range at gain = 64, 4 kSPS

Total harmonic distortion: –100 dB

Crosstalk between channels: –120 dB

Low-drift internal voltage reference

Cyclic redundancy check (CRC) on communications and register map

2.7V to 3.6V analog and digital supplies

Low power consumption: 6.0 mW at 3-V AVDD and DVDD

Packages: 32-pin TQFP or 32-pin WQFN

Operating temperature range: –40°C to +125°C

Applications

Electricity meters: commercial and residential

Circuit breakers

Protection relays

Power quality meters

Battery test equipment

Battery management systems
