The STPSC40H12CWL SiC diode in a TO-247 LL package is an ultra-high efficiency Schottky power rectifier. It is manufactured using a silicon carbide substrate. The wide band gap material gives the Schottky diode structure a low VF and a voltage rating of 1200 V. Due to the Schottky structure, there is no recovery when switching and the ringing mode is negligible. The minimum capacitive behaviour at switch-off is independent of temperature.

Features

- No reverse recovery or negligible

- Temperature-independent switching behaviour

- Robust high voltage peripherals

- Operating temperature of -40°C to 175°C

- Low VF

- ECOPACK® compliant components

Specification

Product Type: Schottky Diodes and Rectifiers

Product: Schottky Silicon Carbide Diodes

Mounting Style: Through Hole

Package / Case: TO-247-LL-3

Configuration: Dual

Technology: SiC

If - Forward current: 20 A

Vrrm - Repeated reverse voltage: 1.2 kV

Vf - Forward voltage: 1.35 V

Ifsm - Forward inrush current: 700 A

Ir - Reverse current: 10 uA

Min. operating temperature: - 40 C

Maximum operating temperature: + 175 C

Series: STPSC40H12C

Factory packed quantity: 600

Vr - Reverse voltage: 800 V

Unit weight: 6.100 g
