TPS65250RHAT: 4.5V to 18V input, 3A/2A/2A output, three-channel synchronous buck converter
1. TPS65250RHAT Product Overview and Supply Background
Shenzhen Mingjiada Electronics Co., Ltd. — long-term supplier of genuine TPS65250RHAT chips (TI three-channel synchronous buck converter). The TPS65250RHAT is packaged in a VQFN-40 package, with an input voltage range of 4.5V to 18V, supporting three independent outputs (3A/2A/2A), and is optimised for high-efficiency power management systems.
2. Core Features of the TPS65250RHAT
High-Efficiency Multi-Output
Three synchronous buck channels: Buck 1 supports 3A continuous load (maximum 3.5A), Buck 2/3 supports 2A continuous load (maximum 2.5A), with integrated power MOSFETs, significantly reducing the number of external components.
Flexible output voltage configuration: Each output can be adjusted within the range of 0.8V to (input voltage - 1V) via an external resistor divider, with accuracy up to 1%.
Intelligent control and protection features
Dynamic frequency adjustment: Switching frequency is adjustable between 300kHz and 2.2MHz via an external resistor, with support for external clock synchronisation to reduce noise.
Dying Gasp mode: Integrated storage/release circuitry maintains system operation during sudden input voltage drops, reducing the need for external capacitors.
Multiple Protection Mechanisms: Includes adjustable current limit (RLIMx pin), soft-start control, enable sequencing, and power good (PGOOD) monitoring.
Thermal Management and Package Optimisation
40-pin VQFN-EP package (6mm × 6mm × 0.95mm) with exposed pad on the bottom for enhanced heat dissipation, suitable for high-density PCB designs.
Wide operating temperature range: -40°C to 125°C, meeting industrial and automotive environment requirements.
3. TPS65250RHAT Specifications and Parameters
Mounting style: SMD/SMT
Package/housing: VQFN-40
Topology: Buck
Output voltage: 800 mV to 17 V
Output current: 3 A
Number of Outputs: 3 Outputs
Input Voltage - Minimum: 4.5 V
Input Voltage - Maximum: 18 V
Quiescent Current: 1.5 mA
Switching Frequency: 300 kHz to 2.2 MHz
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: +125°C
4. Typical Application Scenarios
The TPS65250RHAT is specifically designed for multi-voltage rail systems, particularly suitable for:
Network communication equipment: xDSL/xPON modems, cable modems, and wireless routers supporting 5V/9V/12V/15V input systems.
Smart home and gateways: home gateways, power line modems (PLC), optimising standby power consumption with its low-power mode.
Consumer electronics: set-top boxes (STB) and access point devices, simplifying power architecture with multiple outputs.
【Mingjiada Electronics】long-term supply of TI (TPS65250RHAT) featuring a three-channel synchronous wide input range high-efficiency buck converter. For more information about the TPS65250RHAT product or to inquire about pricing, please contact Mingjiada Electronics:
