STMicroelectronics VNH5200ASTR: Automotive-grade Fully Integrated H-Bridge Motor Driver IC
Mingjiada Electronics offers genuine STMicroelectronics VNH5200ASTR automotive-grade fully integrated H-bridge motor driver chips from stock.Product Description:The VNH5200ASTR is an automotive-grade (AEC-Q100 qualified), fully integrated H-bridge mot…
Mingjiada Electronics offers genuine STMicroelectronics VNH5200ASTR automotive-grade fully integrated H-bridge motor driver chips from stock.
Product Description:
The VNH5200ASTR is an automotive-grade (AEC-Q100 qualified), fully integrated H-bridge motor driver IC. Housed in a SOIC-16 package, it supports a wide input voltage range from 5.5V to 18V and delivers up to 8A of continuous output current.
This driver utilises STMicroelectronics' advanced VIPower® M0 technology, enabling efficient integration of power MOSFETs and intelligent signal/protection circuits on a single die. Its fully symmetrical mechanical design delivers exceptional manufacturability at the board level. Engineered to meet stringent automotive electronics requirements, it is suitable for driving various brushed DC motors.
Brand: STMicroelectronics (ST)
Model: VNH5200ASTR
Year: 23+
Package: SO-16N
Key Parameters:
Motor Type: Brushed DC
Function: Fully integrated driver, control and power stage
Output Configuration: Half-bridge (2)
Interface: On/Off
Technology: Power MOSFET
Output Current: 8A
Supply Voltage: 5.5V to 18V
Load Voltage: 5.5V to 18V
Operating Temperature: -40°C to 150°C (TJ)
Grade: Automotive
Mounting Type: Surface Mount
Package/Case: 16-SOIC
Features:
Integrated H-bridge driver circuit: Enables forward/reverse motor control, suitable for DC motor drive applications.
Multiple protection mechanisms: Includes overcurrent, overtemperature, and undervoltage protection to ensure motor and driver safety.
PWM speed control: Adjusts motor speed via PWM signal duty cycle for enhanced control and energy efficiency.
High Integration: Combines control and power stages, reducing external component requirements while enhancing system reliability and simplicity.
Application Scenarios
The VNH5200ASTR finds extensive use in the following domains:
Automotive Applications: Suitable for motor drive in diverse automotive electronic systems.
Automation Equipment: Delivers outstanding performance in robotics, electric toys, automatic doors, conveyor belts, and similar applications.
