Overview: The MP86941-CGQVT is a high-efficiency synchronous buck DC-DC converter that integrates high-side and low-side MOSFETs, supports a wide input voltage range, and features high conversion efficiency and low quiescent current. It is suitable for applications such as industrial automation, communication equipment, server power supplies, and consumer electronics. Low latency: Features low latency, making it suitable for high-speed applications. Over-temperature protection: Built-in over-temperature protection functionality automatically shuts down the chip when the temperature exceeds safe limits.

Features:

High-efficiency conversion: Achieves up to 95% efficiency, maintaining high efficiency across a wide load range, helping to reduce power consumption and enhance system performance.

Wide input voltage range: Supports an input voltage range of 3V to 60V, accommodating diverse power supply environments and suitable for applications requiring a wide input voltage range.

Adjustable output voltage: The output voltage range is 0.8V to 30V, which can be flexibly set via external resistors to meet the output voltage requirements of different applications.

High switching frequency: Supports a switching frequency of up to 2MHz, allowing the use of smaller external components, thereby reducing the overall solution size and cost.

Rich feature set: Built-in multiple protection functions, including cycle-by-cycle current limiting, over-temperature protection, under-voltage lockout (UVLO), short-circuit protection, and programmable soft-start, ensuring stable and reliable operation under various operating conditions.

MP86941-CGQVT product parameters:

Wide input voltage range: 3.3V to 18V

Wide output voltage range: 0.8V to 30V

Maximum output current: 3A

Quiescent current (disabled mode): 10µA

Operating temperature range: -40°C to +150°C

Package type: QFN, dimensions: 3mm × 3mm × 0.8mm

Frequency range: Supports switching frequencies up to 2MHz

If you are interested in the MP86941-CGQVT chip or require further product information, please contact Mingjiada Electronics Customer Service (Phone: +86 13410018555, Email: sales@hkmjd.com).
