Product Description

The Samtec HSEC8-140-01-L-RA-TR is a right-angle 0.80 mm pitch edge card connector that is part of Samtec's Edge Rate® connector system, designed for high-speed applications and supports multiple protocols with high signal integrity and reliability.

Features (HSEC8-140-01-L-RA-TR)

High Density Design: The 0.80 mm pitch allows the connector to provide more connection points in a limited space, making it suitable for high density electronic device designs.

High-speed transmission capability: Supports transmission rates up to 28 Gbps NRZ/56 Gbps PAM4 for high-speed data transmission applications.

Ruggedised Edge Rate Termination System: Features a robust terminal design that withstands high insertion and removal counts, and mates with up to 1.5 mm terminal slide range for improved mating angle tolerances.

Signal Integrity Optimisation: The smooth, wide, milled mating surfaces of the Edge Rate terminals minimise the effects of broadside coupling and reduce crosstalk for excellent signal integrity.

Multiple Mounting Orientations: The connectors are available in a variety of mounting orientations, including vertical, right-angle, edge-mount, and straight-through, providing design flexibility.

Compatibility: Compatible with PCI Express® Generation 3, there is also a low-profile version compatible with Generation 4.

Power and Signal Combination: The HSEC8-PV series combines high-speed signal and power terminals to meet different application requirements.

Technical Data (HSEC8-140-01-L-RA-TR)

Pitch: 0.80 mm

Operating Voltage: Depends on the specific configuration and application environment, but can usually support common electronic system operating voltage.

Operating temperature range: -55°C ~ +125°C

Package Format: Surface Mount (SMD)

Total number of PINs: 80P

Contact Material: Copper Beryllium

Contact plating: Gold

Application Areas (HSEC8-140-01-L-RA-TR)

Data communication equipment: In high-speed data transmission equipment such as servers, data centre switches, etc., it is used to connect the motherboard with various expansion cards and modules to guarantee fast and accurate data transmission.

Industrial automation: It can be used in industrial robots, programmable logic controllers (PLC) and automated production line equipment to connect different functional modules, sensors and actuators.

Aerospace and defence: With its high reliability and resistance to harsh environments, it provides a solid connection for key electronic equipment such as avionics systems, missile guidance equipment and military communication equipment.

As a professional electronic components supplier, Mingjiada Electronics provides high quality Samtec HSEC8-140-01-L-RA-TR connectors to ensure stable supply and quality assurance. If interested in Samtec HSEC8-140-01-L-RA-TR or have related needs, please feel free to contact Mingjiada Electronics for more information.
