The STGW30NC120HD device is an N-channel 1200 V, 30 A ultra-fast PowerMESH IGBT, which is particularly suitable for applications requiring soft switching, such as inverters and motor drives.

Its main characteristics

Low conduction loss ‌ : The STGW30NC120HD features low conduction loss and is suitable for applications that require high performance conversion.

Youdaoplaceholder0 Low on-voltage drop ‌ : At 25°C, the STGW30NC120HD has an on-voltage of 2.75V, ensuring low power consumption operation.

Youdaoplaceholder0 High current capability ‌ : With a current of 30A, the STGW30NC120HD is suitable for applications that require high current output.

Youdaoplaceholder0 High input impedance ‌ : STGW30NC120HD is voltage-driven and suitable for high-frequency applications.

Youdaoplaceholder0 Low gate charge ‌ : STGW30NC120HD reduces energy loss during switching.

Brief Introduction

The STGW30NC120HD is an advanced 1200V IGBT device designed based on ST's patented bar layout and adopting the latest high-voltage technology, featuring outstanding performance. This IGBT has been optimized for high-frequency applications to achieve very high switching performance (reducing tfall) while maintaining a low voltage drop.

Technical Specification

The STGW30NC120HD has the following main specifications:

Configuration: Single

The maximum collector-emitter voltage VCEO: 1.2 kV

Collector-emitter saturation voltage: 2.75V

Maximum gate/emitter voltage: -25V, 25V

Continuous collector current at 25 C: 60 A

Pd- Power dissipation: 220 W

Minimum operating temperature: -55 ° C

Maximum operating temperature: + 150 ° C

Series: STGW30NC120HD

Installation style: Through Hole

Package/Box: TO-247-3

Collector continuous current: 30 A

The maximum continuous current Ic at the collector: 60 A

Gate-emitter leakage current: +/- 100 nA

Height: 20.15mm

Length: 15.75mm

Product type: IGBT Transistors

Width: 5.15mm

Unit weight: 38 g

Application field

The STGW30NC120HD is suitable for various application scenarios that require high performance and high-frequency switching, such as induction heating, motor control, power management, etc. Its excellent performance makes it have broad application prospects in industrial automation, power electronics equipment, new energy vehicles and other fields ‌.
