Mingjiada Electronics Supply TI (UCC27524ADR) 5A/5A Dual Channel Low Side Gate Driver

Shenzhen Mingjiada Electronics Co., Ltd.: Professional supply TI (UCC27524ADR) with negative input voltage capability of 5A high-speed low-side gate driver, empowering high-efficiency power system design.

Overview:

Mingjiada Electronics has been supplying TI (UCC27524ADR) high-speed low-side gate driver for a long time, which is a 5A/5A dual-channel gate driver with 5V UVLO, enable function, and 1ns delay matching.The UCC27524ADR is capable of delivering high peak current pulses of up to 5A pull and 5A sink current to capacitive loads.The UCC27524ADR is also capable of rail-to-rail driving and has the ability to deliver high peak current pulses of up to 5A pull and 5A sink currents to capacitive loads. The UCC27524ADR is capable of delivering high peak current pulses of up to 5A pull current and 5A sink current into capacitive loads.

I. UCC27524ADR Core Specification Parameters

Drive Configuration: Low-end

Channel Type: Standalone

Number of drivers: 2

Gate Type: IGBT, MOSFET (N-channel)

Voltage - Supply: 4.5V ~ 18V

Logic Voltage - VIL, VIH: 1V, 2.3V

Current - Peak Output (Pour In, Pull Out): 5A, 5A

Input Type: Non-Inverting

Rise/Fall Time (typical): 7ns, 6ns

Operating Temperature: -40°C ~ 140°C (TJ)

Mounting Type: Surface Mount

Package/Shell: 8-SOIC (0.154’, 3.90mm Width)

II. UCC27524ADR Core Product Features

Two independent gate drive channels

5A peak pull and sink currents

Independent enable function for each output

TTL and CMOS compatible logic thresholds (supply voltage independent)

Hysteresis logic thresholds for high noise immunity

Capable of handling negative voltages (-5V) on inputs

Input and enable pin voltage levels are not limited by auxiliary supply voltage on VDD pin

4.5V to 18V single supply voltage range

Outputs held low during VDD undervoltage lockout (UVLO) (ensures interference-free operation during power-up and power-down)

Short propagation delay (17ns typical)

Fast rise and fall times (6ns and 10ns typical, respectively)

1ns typical for delay matching between two channels

Two outputs in parallel for higher drive current

Outputs held low when inputs are dangling

Operating junction temperature range: -40°C to 150°C

Typical Application Scenarios for the UCC27524ADR

Switching mode power supplies

DC/DC converters

Motor control, solar

Gate drive for new-to-market wide bandgap power devices such as GaNs

The UCC27524ADR has become a popular choice for industrial, automotive and energy applications due to its high speed and high drive capability. Mingjiada Electronics is always committed to providing customers with high-performance and high-reliability power device solutions. Whether it's a new project development or mass production needs, Mingjiada can provide you with full-process support from selection to delivery!

Welcome to visit our website or contact our sales team for UCC27524ADR parameter data and exclusive quotation!
