[ADI Analog-to-Digital Converters] AD7383BCPZ-Dual Simultaneous Sampling, 16-Bit, 4 MSPS, SAR ADC

Product features

1, the AD7383BCPZ has two complete ADC functions, supporting dual channel synchronous sampling and conversion.

2, pin-compatible product series.

3. The AD7383BCPZ has a high throughput rate of 4 MSPS.

4. The AD7383BCPZ uses a space-saving 3 mm × 3 mm LFCSP package.

5, Integrated oversampling module can improve dynamic range, reduce noise, and reduce SCLK speed requirements.

6. Pseudo differential simulation input.

7, small sampling capacitance can reduce the amplifier drive burden.

AD7383BCPZ block diagram

Application scenario

The AD7383BCPZ is suitable for a variety of applications that require high precision and high speed data acquisition, including:

Motor control position feedback

Motor control current detection

sonar

Power quality

Data acquisition system

Application of erbium-doped fiber amplifier (EDFA)

I/Q demodulation

Features of the AD7383BCPZ include:

Dual-channel 16-bit ADC series

Dual synchronous sampling

Fully differential analog input

4 High throughput conversion rate of MSPS.

SNR (typical value)

87.5dB, VREF = 3.3V external for the 16-bit AD7383

83.5dB, VREF = 3.3V External for the 16-bit AD7384

93.4 dB When RES = 1 and OSR = 8

On-chip oversampling function

Resolution boost function

INL error (maximum)

2.5 LSBs, 16-bit AD7383

1.0 LSB, 14-bit AD7384

2.5V internal reference voltage source

High speed serial interface

Operating temperature range −40°C to +125°C

16-pin LFCSP, 3 mm x 3 mm

Alarm function

Product information

The AD7383BCPZ is a dual-channel synchronous sampling, high speed, low power, Successive Approximation Register (SAR) analog-to-digital converter (ADC) powered from 3.0V to 3.6V with throughput rates up to 4 MSPS. The analog input type is pseudo differential, and sampling and conversion are performed at the CS falling edge. An integrated on-chip oversampling module improves dynamic range and reduces noise at lower bandwidth. The AD7383BCPZ has a built-in 2.5V buffer reference voltage source. Alternatively, an external reference voltage source of up to 3.3V can be used.

Both the conversion process and the data acquisition process use standard control inputs and can be easily interlinked with a microprocessor or digital signal processor (DSP). When using a standalone logic power supply, the AD7383BCPZ is compatible with 1.8V, 2.5V and 3.3V interfaces.
