Supply Original LDO Regulator (TPS7A8400ARGRR) TI Low Dropout Linear Regulators

Shenzhen Mingjiada Electronics Co., Ltd.——Long term supply TI (TPS7A8400ARGRR) high accuracy 0.75%, low noise 4.4µVRMS, low dropout linear regulator.

Here are the product details about TI (TPS7A8400ARGRR) LDO Regulator:

Basic Information:

Model No.: TPS7A8400ARGRR

Package: VQFN-20

Type: Low Dropout Linear Regulator

Product Description: TPS7A8400ARGRR - 3A, low input voltage regulator with Power Normal TPS7A8400ARGRR - 3A, Low Input Voltage (1.1V), Low Noise, High Precision, Ultra Low Dropout Regulator with Power Normal Indication.

TPS7A8400ARGRR Product Diagram:

TPS7A8400ARGRR Specifications:

Output Configuration: Positive

Output Type: Adjustable/Programmable

Number of Regulators: 1

Voltage - Input (Maximum): 6.5V

Voltage - Output (Minimum/Fixed): 0.8V

Voltage - Output (Maximum): 5.15V

Voltage Dropout (Maximum): 0.45V @ 3A

Current - Output: 3A

Current - Static (Iq): 3 mA

Current - Supply (Max): 5.5 mA

PSRR: 42dB ~ 25dB (10kHz ~ 500kHz)

Control Characteristics: Enable, Power Good, Soft-Start

Protections: Overcurrent, Overtemperature, Undervoltage Lockout (UVLO)

Operating Temperature: -40°C ~ 125°C (TJ)

Mounting Type: Surface Mount

Package/Case: 20-VFQFN Unpotted Pad

Supplier Device Package: 20-VQFN (3.5x3.5)

TPS7A8400ARGRR Product Characteristics:

Low dropout: 180mV (max) at 3A, biased

Maximum accuracy over line, load, and temperature ranges of 0.75%, biased

Output Voltage Noise: 4.4µVRMS

Input Voltage Range:

Unbiased: 1.4V to 6.5V

Biased: 1.1V to 6.5V

TPS7A8400ARGRR Output Voltage Range:

Adjustable Operating Voltage: 0.8V to 5.15V

ANY-OUT™ Operating Voltage: 0.8V to 3.95V

Power Supply Ripple Rejection:

40dB at 500kHz

Outstanding Load Transient Response

Adjustable Soft-Start Surge Control

Open Drain Power Gain (PG) Outputs

【Mingjiada Electronics】Long-term supply of TI (TPS7A8400ARGRR) low noise, low dropout linear regulator (LDO), can provide 3A pull current, the maximum dropout is only 180mV. TPS7A8400ARGRR has a high-performance, can suppress the power supply generated by the phase noise and clock jitter, so it is ideal for high-performance serializer and deserializer ( SerDes), the TPS7A8400ARGRR. SerDes, analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and RF components. The device's high performance and greater than 5V output capability make it particularly well suited for RF amplifiers.
