Product Overview

The LPC54101J256UK49 from NXP is a high-performance, low-power 32-bit microcontroller (MCU) based on the ARM Cortex-M4 core, designed for application scenarios requiring high-performance processing and low-power operation. As a member of the LPC54000 series, the LPC54101J256UK49 is widely used in smart wearable devices, Internet of Things (IoT), and industrial control with its excellent performance and flexible configuration.

The LPC54101J256UK49 is available in a WLCSP-49 package measuring only 3.29 x 3.29 x 0.54 mm, making it ideal for space-constrained designs. With a core frequency of up to 100 MHz, 256 KB of Flash and 104 KB of SRAM, the LPC54101J256UK49 meets the data processing needs of complex applications.

Product Features

Dual-core architecture

The LPC54101J256UK49 is available with an optional ARM Cortex-M0+ co-processor, which works in tandem with the Cortex-M4 core for efficient tasking and power optimisation, and the Cortex-M4 core, which supports floating-point operations (FPU) and a memory protection unit (MPU) for high-performance computing, and the Cortex-M0+ core, which is known for its low power consumption and suitable for processing complex applications. Cortex-M0+ cores are known for their low power consumption and are suitable for lightweight tasks.

Low-power design

With a current as low as 3 µA in low-power mode and support for multiple power-saving modes such as sleep mode, deep sleep mode, etc., the MCU is ideal for battery-powered devices. Its flexible power management unit (PMU) dynamically adjusts power consumption according to application requirements.

Rich Peripheral Resources

Communication interface: Supports various communication protocols such as I2C, SPI, UART, etc. to meet diversified data transmission needs.

Analogue function: Integrated 12-bit ADC with sampling rate up to 4.8 MSamples/s, supporting multi-channel data acquisition.

Timer and PWM: Built-in multiple 32-bit timer and PWM modules, suitable for precise control applications.

High Reliability

The LPC54101J256UK49 meets industrial-grade standards and operates over a temperature range of -40°C to +105°C, making it suitable for harsh environments. Its built-in watchdog timer (WDT) and power monitoring functions further enhance system stability.

Application Scenarios

Smart Wearable Devices

The low power consumption of the LPC54101J256UK49 makes it ideal for applications such as smartwatches and health monitoring devices. Its high-performance core enables fast processing of sensor data while extending battery life.

Internet of Things (IoT)

In the IoT field, the LPC54101J256UK49 supports a wide range of communication protocols, enabling seamless connectivity and data transfer between devices. Its low-power design is particularly suitable for sensor nodes that require long-term operation9.

Industrial Control

The MCU's high reliability and rich peripheral resources make it suitable for industrial automation, motor control and other scenarios. Its powerful processing capability can meet the needs of complex control algorithms.

Mingjiada Electronics Supply Information

Mingjiada Electronics has been supplying LPC54101J256UK49 for a long time to ensure the original and reliable quality of our products. We provide the following services:

Spot supply: sufficient stock to meet the urgent needs of customers.

Technical support: professional technical team to provide customers with selection, design and debugging support.

Price Advantage: With strong supply chain management capabilities, we provide customers with competitive prices.

Summary

With its high performance, low power consumption and rich peripheral resources, the LPC54101J256UK49 is an ideal choice for many embedded applications. Whether it's smart wearables, IoT or industrial control, the LPC54101J256UK49 delivers outstanding performance and reliability.

For more information about LPC54101J256UK49 or for purchasing support, please contact Mingjiada Electronics, we will be happy to serve you!
