Shenzhen Mingjiada Electronics Co., Ltd.——[Supply] TMS320F28377DZWTQR (TI) Dual-Core Automotive C2000™ 32-Bit Microcontrollers

The TMS320F28377DZWTQR is a powerful 32-bit floating-point microcontroller (MCU) designed for advanced closed-loop control applications.The TMS320F28377DZWTQR supports the new dual-core C28x architecture, which significantly improves system performance. The integrated analog and control peripherals also enable designers to consolidate control architectures, eliminating the need for multiple processors in high-end systems. the TMS320F28377DZWTQR also supports up to 1MB (512KW) of on-board Flash with Error Correcting Code (ECC), and up to 204KB (102KW) of SRAM. there are also two 128-bit security zones on each CPU for code protection. code protection.

TMS320F28377DZWTQR - Product Attributes:

Family: C2000™ C28x Delfino™, Functional Safety (FuSa)

Core Processor: C28x

Core Specification: 32-bit Dual Core

Speed: 200MHz

Connectivity: CANbus, EBI/EMI, I2C, McBSP, SCI, SPI, uPP, UART/USART, USB

Peripherals: DMA, POR, PWM, WDT

Number of I/O: 169

Program memory capacity: 1MB (512K x 16)

Program memory type: Flash

RAM Size: 102K x 16

Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.47V

Data Converter: A/D 24x12b, 12x16b; D/A 3x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Supplier Device Package: 337-NFBGA (16x16)

Package/Housing: 337-LFBGA

TMS320F28377DZWTQR - Key Features:

Core.

Dual Core Architecture: Two TMS320C28x 32-bit CPUs up to 200 MHz.

Floating Point Unit (FPU): Each core is equipped with a floating point unit to support single precision floating point operations.

Memory: Flash: 1MB (512KB)

Flash: 1MB (512KB per core)

RAM: 204KB (102KB per core)

OTP: 1KB

Peripherals

PWM module: 16 high-resolution PWM channels with resolutions up to 150 ps.

ADCs: Two 12-bit ADCs with conversion rates up to 3.5 MSPS.

Comparators: 8 high precision comparators.

Communication interfaces: CAN, I2C, SPI, SCI, LIN, etc.

Security.

Encryption Accelerator: Support AES, DES, SHA and other encryption algorithms.

Secure Boot: Supports secure boot and firmware update.

Package Type: 337-ball NFBGA (ZWT)

Operating temperature: -40°C to +125°C

TMS320F28377DZWTQR - Typical Applications:

Motor Control: TMS320F28377DZWTQR is used in electric vehicles, industrial motors, and more.

Power management: for solar inverters, UPS, etc..

Automotive electronics: for engine control unit, battery management system, etc..

TMS320F28377DZWTQR - Advantages:

High performance: Dual-core architecture and floating-point unit provide powerful computing capability.

High Integration: Rich peripherals and interfaces reduce the need for external components.

High Reliability: Meets automotive grade standards for harsh environments.

[Shenzhen Mingjiada Electronics Co., Ltd.] is a long term supplier of TMS320F28377DZWTQR Automotive C2000™ 32-bit MCU, for more information about TMS320F28377DZWTQR, visit Mingjiada Electronics official website (www.hkmjd.com) and contact our sales team.
