[Distribution onsemi] AR0330CM1C12SHKA0-CP CMOS Image Sensor, 3 Megapixel, 1/3 inch

[Distribution onsemi] AR0330CM1C12SHKA0-CP CMOS Image Sensor, 3 Megapixel, 1/3 inch

Source:our siteTime:2023-11-17Views:

Shenzhen Mingjiada Electronic new and original [distribution onsemi] AR0330CM1C12SHKA0-CP CMOS image sensor, 3 megapixels, 1/3 inchProduct Description ON Semiconductors AR0330CM1C12SHKA0-CP is a 1/3-inch CMOS digital image sensor with an active pixel …

Shenzhen Mingjiada Electronic new and original [distribution onsemi] AR0330CM1C12SHKA0-CP CMOS image sensor, 3 megapixels, 1/3 inch


Product Description

ON Semiconductor's AR0330CM1C12SHKA0-CP is a 1/3-inch CMOS digital image sensor with an active pixel array of 2304 (H) × 1536 (V). It supports 3.15 Mp (2048 (H) × 1536 (V)) digital still image capture and 1080p60 + 20% EIS (2304 (H) × 1296 (V)) digital video mode. It integrates advanced on-chip camera functions such as windowing, mirroring, column and row subsampling modes, and snapshot mode.


Specification

Model No.: AR0330CM1C12SHKA0-CP

Product Status: On Sale

Type: CMOS

Pixel Size: 2.2µm x 2.2µm

Active pixel array: 2304H x 1296V

Frames per second: 60

Voltage - Supply: 1.7V ~ 1.9V

Package/Housing: 64-VFBGA, CSPBGA

Supplier Device Package: 64-CSP (6.28x6.65)

Operating Temperature: -30°C ~ 70°C (TJ)


Applications

- 1080p HD Digital Video Cameras

- Network and Video Conferencing Cameras

- Security Cameras


Summary

Onsemi's mainstream CMOS image sensors offer a wide range of performance, size, power, and resolution options to meet the requirements of IoT ecosystems and usage models. CMOS image sensors use advanced CMOS manufacturing processes to enable superior imaging. This includes vibrant colour images for human eye viewing, detailed monochrome images for machine vision, and light industrial uses. The mainstream image sensors feature VGA to 18MP resolutions, 30fps to 120fps frame rates, and 1.1µm to 6µm pixel sizes. Typical applications include smart lighting, connected doorbells, home appliances, robotics and 2D scanners.
