Shenzhen Mingjiada Electronics Co., Ltd. is now offering brand-new, genuine Infineon driver IC 2EDF7175F, a fast, reliable, dual-channel, functionally isolated MOSFET gate driver with accurate and stable timing performance.

Product Overview

The Infineon EiceDRIVER™ 2EDF7175F is specifically designed for primary-side control of high-side and low-side MOSFETs in high-noise, high-power switching environments, ensuring reliable and stable operation. The driver features a powerful 4A/8A source/drain dual-channel gate driver, enabling fast turn-on/turn-off of high-voltage and medium-voltage MOSFETs (such as CoolMOS™ or OptiMOS™). Both output channels are independently isolated and can be used as floating gate drivers, with CMTI performance up to 150V/ns.

Features

• 4 A/8 A or 1 A/2 A source/sink output current

• Maximum 10 MHz PWM switching frequency

• Typical PWM signal propagation delay of 37 ns, where

–   3 ns channel-to-channel mismatch

–   Propagation delay variation of +7/-6 ns

• Common-mode transient immunity (CMTI) >150 V/ns

• Fast safe shutdown upon input under-voltage lockout (UVLO)

• Output supply voltage range of 4.5 V to 20 V, with UVLO thresholds of 4 V or 8 V

• Wide temperature operating range of TJ = -40°C to +150°C

• RoHS-compliant wide/narrow body (WB/NB) DSO16 and 5 mm × 5 mm LGA packages

• Fully compliant with JEDEC standards, suitable for industrial applications

Potential applications

• Switching power supplies (SMPS) for servers, telecommunications, and industrial applications

• Synchronous rectification, brick converters, uninterruptible power supplies (UPS), and battery energy storage systems

• Electric vehicle charging industry automation, motor drives, and power tools

2EDF7175F Specifications

Model: 2EDF7175F

Brand: Infineon

Package: DSO-16 (PG-DSO-16-11)

Channel Count: Dual-channel (independent isolation)

Drive Current: 4A (sink) / 8A (source)

CMTI: 150V/ns

Rise/Fall Time: 6.5ns / 4.5ns

Operating Temperature: -40°C to +125°C

Isolation Type: Functional isolation (core-less transformer CT technology)

Mingjiada Electronics, as a professional electronic component supplier, offers brand-new genuine Infineon driver IC 2EDF7175F. For inquiries or purchases of 2EDF7175F, please contact Mingjiada Electronics:

Phone: +86 13410018555

Email: sales@hkmjd.com

Website: www.hkmjd.com
