Shenzhen Mingjiada Electronics Imported Original Supply STMicroelectronics STM32F072R8T7 Mainstream ARM Cortex-M0 USB Series MCU with 64 KB Flash, 48 MHz CPU, USB, CAN and CEC Functions

Descripción

The STM32F072R8T7 microcontrollers integrate a high-performance ARM®Cortex®-M0 32-bit RISC core operating at up to 48 MHz, high-speed embedded memory (up to 128 Kbytes of Flash and 16 Kbytes of SRAM), and a wide range of enhanced peripherals and I/O. All devices offer standard communication interfaces (two I2C, two SPI/I2S, and two USB). All devices offer standard communication interfaces (two I2C, two SPI/I2S, one HDMI CEC, and four USARTs), a USB full-speed device (no crystal), a CAN, a 12-bit ADC, a dual-channel 12-bit DAC, seven 16-bit timers, a 32-bit timer, and an advanced control PWM timer.

The STM32F072x8/xB microcontrollers operate over the -40 to +85 °C and -40 to +105 °C temperature ranges and are supplied from 2.0 to 3.6 V. A full suite of power-save modes allows for the design of low-power applications.

The STM32F072x8/xB microcontrollers include devices in seven different packages, ranging from 48-pin to 100-pin, and are also available in die form upon request. Depending on the device selected, different peripherals are also included.

These features make the STM32F072x8/xB microcontrollers suitable for a wide variety of applications such as application control and user interfaces, handheld devices, A/V receivers and digital TVs, PC peripherals, gaming and GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVAC.

Product Attributes

Product Category: ARM Microcontrollers - MCUs

Family: STM32F072R8

Mounting Style: SMD/SMT

Package / Case: LQFP-64

Core: ARM Cortex M0

Program memory size: 64 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Maximum clock frequency: 48 MHz

Number of inputs/outputs: 51 I/Os

Data RAM size: 16 kB

Supply voltage - min: 2 V

Supply voltage - max: 3.6 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 105 C

Analogue supply voltage: 2.4 V to 3.6 V

DAC resolution: 12 bit

Data Ram type: SRAM

I/O Voltage: 1.65 V to 3.6 V

Interface Type: CAN, HDMI, I2C, LIN, SPI, USART, USB

Humidity Sensitivity: Yes

Number of ADC channels: 19 Channel

Number of timers/counters: 1 x 32 bit, 8 x 16 bit

Programme memory type: Flash

Circuit Schematic
