[Supply, Recycle] LAN7850-I/8JX Hi-Speed USB 2.0 to 10/100/1000 Ethernet Controller with HSIC

[Supply, Recycle] LAN7850-I/8JX Hi-Speed USB 2.0 to 10/100/1000 Ethernet Controller with HSIC

Source:our siteTime:2023-11-17Views:

Shenzhen Mingjiada Electronics Co., Ltd. [Supply, Recycle] LAN7850-I/8JX Hi-Speed USB 2.0 to 10/100/1000 Ethernet Controller with HSICGeneral DescriptionLAN7850-I/8JX is a high performance Hi-SpeedUSB 2.0 to 10/100/1000 Ethernet controller with an int…

Shenzhen Mingjiada Electronics Co., Ltd. [Supply, Recycle] LAN7850-I/8JX Hi-Speed USB 2.0 to 10/100/1000 Ethernet Controller with HSIC


General Description

LAN7850-I/8JX is a high performance Hi-SpeedUSB 2.0 to 10/100/1000 Ethernet controller with an integrated 10/100/ 1000 Ethernet PHY and High-Speed Inter-Connect (HSIC) interface. It is a high performance and cost effective USB/HSIC to Ethernet connectivity solution.

The LAN7850 contains an integrated 10/100/1000 Ethernet MAC and PHY, Filtering Engine, USB PHY (with HSIC interface), Hi-Speed USB 2.0 device controller, TAP controller, EEPROM controller, and a FIFO controller with internal packet buffering.


Product Features

Single Chip Hi-Speed (HS) USB 2.0 to 10/100/1000 Ethernet Controller

- Integrated Gigabit PHY with HP Auto-MDIX

- Integrated 10/100/1000 Ethernet MAC (Full-Duplex Support)

- Integrated USB 2.0 Device Controller

- Integrated USB PHY

Power and I/Os - Variable voltage I/O supply (1.8V-3.3V)

USB 2.0 Device Controller

- Supports HS (480Mbps), and FS (12Mbps) modes

- Four endpoints supported

- Supports vendor specific commands

- Remote wakeup supported

- Integrated HSIC interface

Environmental

- Commercial temperature range (0°C to +70°C)

- Industrial temperature range (-40°C to +85°C)


Target Applications

Automotive Infotainment

Notebook/Tablet Docking Stations

Detachable Laptops

USB Port Replicators

Standalone USB to Ethernet Dongles

Embedded Systems / CE Devices


If you have a requirement, please call Mr. Chen for advice at:

Tel: +86 13410018555

E-mail: sales@hkmjd.com

Home page URL: www.hkmjd.com
