[Supply, Recycle] 32MHz STM32L072CBT6 (ST) 32-Bit Single-Core Microcontroller, 48-LQFP

[Supply, Recycle] 32MHz STM32L072CBT6 (ST) 32-Bit Single-Core Microcontroller, 48-LQFP

Source:our siteTime:2023-11-14Views:

Shenzhen Mingjiada Electronics Co., Ltd. [Supply, Recycle] 32MHz STM32L072CBT6 (ST) 32-Bit Single-Core Microcontroller, 48-LQFPProduct DescriptionSTM32L072CBT6 incorporate the connectivity power of the universal serial bus (USB 2.0 crystal-less) with …

Shenzhen Mingjiada Electronics Co., Ltd. [Supply, Recycle] 32MHz STM32L072CBT6 (ST) 32-Bit Single-Core Microcontroller, 48-LQFP


Product Description

STM32L072CBT6 incorporate the connectivity power of the universal serial bus (USB 2.0 crystal-less) with the high-performance Arm Cortex-M0+ 32-bit RISC core operating at a 32 MHz frequency, a memory protection unit (MPU), highspeed embedded memories (up to 192 Kbytes of Flash program memory, 6 Kbytes of data EEPROM and 20 Kbytes of RAM) plus an extensive range of enhanced I/Os and peripherals.


Product Features

Ultra-low-power platform

– 1.65V to 3.6V power supply

– -40 to 125°C temperature range

– 0.29µA Standby mode (3 wakeup pins)

– 0.43µA Stop mode (16 wakeup lines)

– 0.86µA Stop mode + RTC + 20Kbyte RAM retention

– Down to 93µA/MHz in Run mode

– 5µs wakeup time (from Flash memory)

– 41µA 12-bit ADC conversion at 10ksps

Core: Arm® 32-bit Cortex®-M0+ with MPU

– From 32kHz up to 32MHz max.

– 0.95DMIPS/MHz

Memories

– Up to 192Kbyte Flash memory with ECC

– 20Kbyte RAM

– 6Kbytes of data EEPROM with ECC

– 20byte backup register

– Sector protection against R/W operation

Up to 84 fast I/Os (78 I/Os 5V tolerant)

Up to 24 capacitive sensing channels supporting touchkey, linear and rotary touch sensors

7-channel DMA controller, supporting ADC, SPI, I2C, USART, DAC, Timers


If you have a requirement, please call Mr. Chen for advice at:

Tel: +86 13410018555

E-mail: sales@hkmjd.com

Home page URL: www.hkmjd.com
