NXP T1040NSN7PQB QorIQ T1040 Quad-Core Communications Processors

Product Description of T1040NSN7PQB

QorIQ® T1040NSN7PQB quad-core communication processors support two or four integrated 64-bit e5500 Power Architecture® processor cores with high-performance data path acceleration architecture and network peripheral interfaces required for networking and telecommunications.

Specifications of T1040NSN7PQB

Core：e5500

Number of Cores：4 Core

Data Bus Width：64 bit

Maximum Clock Frequency：1.4 GHz

Package/Case：FCPBGA-780

L1 Cache Instruction Memory：32 kB

L1 Cache Data Memory：32 kB

Operating Supply Voltage：1 V

Series：T1040

Minimum Operating Temperature：0 C

Maximum Operating Temperature：+ 105 C

I/O Voltage：1.2 V to 3.3 V

Interface Type：Ethernet, I2C, PCI-e, Serial, USB

L2 Cache Instruction / Data Memory：256 kB

Memory Type：DDR3L / DDR4 SDRAM

Moisture Sensitive：Yes

Number of I/Os：109 I/O

Unit Weight：1.483 g

Features of T1040NSN7PQB

Core Complex：

Two or four e5500 cores, built on Power Architecture technology

Up to 1.4 GHz with 64-bit ISA support

Three levels of instructions: user, supervisor, hypervisor

Hybrid 32-bit mode to support legacy software and transition to a 64-bit architecture

256 KB backside L2 cache

Networking Elements：

SerDes

Eight lanes at up to 5 Gbps

Supports SGMII, QSGMII, PCIe and SATA

Ethernet Interfaces

Eight-port Gigabit Ethernet switch

Accelerators and Memory Control：

32/64-bit DDR3L/4 SDRAM memory controller with ECC support

Up to 1600 MT/s

DPAA Incorporating acceleration for the following functions Packet parsing, classification, and distribution

Queue management for scheduling, packet sequencing and congestion management

Hardware buffer management for buffer allocation and de-allocation

Integrated security acceleration (SEC)

Signature detection (PME)

Up to five Gigabit Ethernet Interfaces

Basic Peripherals and Interconnect：

CoreNet® platform cache

256 KB shared platform cache

Hierarchical interconnect fabric

CoreNet fabric supporting coherent and non-coherent transactions with prioritization and bandwidth allocation amongst CoreNet endpoints

Additional peripheral interfaces two Serial ATA (SATA 2.0) controllers

Two high-speed USB 2.0 controllers with integrated PHYs

Enhanced secure digital host controller (SD/MMC/eMMC)

Enhanced serial peripheral interface (eSPI)

Two I²C controllers

Four UARTS

Integrated flash controller supporting NAND and NOR flash

DMA

Dual four channel

Up to 5x 1 Gbps Ethernet MACs as part of DPAA

QUICC Engine®

Support for legacy protocols TDM, HDLC, UART and ISDN

High-speed peripheral interfaces

Four PCI Express® 2.0 controllers

Additional Features：

Support for hardware virtualization and partitioning enforcement

Extra privileged level for hypervisor support

QorIQ® trust architecture

Secure boot, secure debug, tamper detection, volatile key storage

Applications of T1040NSN7PQB

Automotive：

Connected Radio

Digital Cluster

eCockpit

Communication Infrastructure：

Broadband Modem and Residential Gateway

Enterprise Access Point

Network Security

Industrial：

Building Energy Management Controller

Electricity Meter

General Avionics

Smart City：

POS Terminal

Smart Home：

Major Home Appliances

Personal/Consumer NAS

Small and Medium Appliances
