For sale NXP RF IC MF3MOD2101DA4/05 RFID Transponder IC 13.56MHz ISO 14443, MIFARE UART MOA4

For sale NXP RF IC MF3MOD2101DA4/05 RFID Transponder IC 13.56MHz ISO 14443, MIFARE UART MOA4

Source:our siteTime:2023-06-28Views:

Mingjiada Electronics Co., Ltd. original stock for sale NXP RF IC MF3MOD2101DA4/05 RFID Transponder IC 13.56MHz ISO 14443, MIFARE UART MOA4Model: MF3MOD2101DA4/05Year: 1846+Package: MOA4Type: RFID Transponder Frequency: 13.56MHz Standard: ISO 14443,…

Mingjiada Electronics Co., Ltd. original stock for sale NXP RF IC MF3MOD2101DA4/05 RFID Transponder IC 13.56MHz ISO 14443, MIFARE UART MOA4


Model: MF3MOD2101DA4/05

Year: 1846+

Package: MOA4

Type: RFID Transponder

Frequency: 13.56MHz

Standard: ISO 14443, MIFARE

Interface: UART

Operating Temperature: -25°C ~ 70°C

Mounting type: Surface mount type

Package/Housing: MOA4, Smart Card Module


Features

RF interface: ISO/IEC 14443 Type A

Contactless data transmission, powered by RF field (no batteries required)

Operating distance: up to 100 mm (depending on the power supply provided by the PCD and the geometry of the antenna)

Operating frequency: 13.56 MHz

Fast data transmission: 106 kbit/s, 212 kbit/s, 424 kbit/s, 848 kbit/s

High data integrity: 16/32 bit CRC, parity check, bit coding, bit counting

True deterministic anti-collision

7-byte unique identifier (option for cascading level 2 and random ID according to ISO/IEC 14443-3)

Uses ISO/IEC 14443-4 protocol

Non-volatile memory

2 kB or 4 kB or 8 kB NV-Memory

Data retention period of 10 years

Write endurance typical 500 000 times

NV-Memory organisation

Flexible file system

Up to 28 applications simultaneously on one PICC

Up to 32 files per application (standard data files, backup data files, numeric files, linear record files and cyclic record files)

File size is determined at creation time


Applications

 Advanced public transport model

 Highly secure access management

 Closed-loop electronic payment solution

 Event ticketing

 e-Government applications

MF3MOD2101DA4 05.jpg

If you are interested, please feel free to contact Mr. Chen at

Tel: +8613410018555

E-mail: sales@hkmjd.com

Company website: www.hkmjd.com
