The NCP1611ADR2G employs an innovative current-controlled frequency foldback (CCFF) approach for driving the PFC boost stage. In this mode, the circuit typically operates in critical conduction mode (CrM) when inductor current exceeds a programmable threshold. As current falls below the preset value, the NCP1611ADR2G linearly attenuates the frequency, reducing to approximately 20kHz when current reaches zero. CCFF technology maximises efficiency under both rated load and light load conditions, notably minimising standby losses. Similar to FCCrM controllers, its internal circuitry maintains near unity power factor even at reduced switching frequencies. Housed in an SO-8 package, this chip integrates all key features required for a robust, compact PFC stage, necessitating minimal external components.

NCP1611ADR2G Features

• Near unity power factor

• Critical conduction mode (CrM)

• Current control frequency foldback (CCFF): Enforces low-frequency operation at low current levels

• On-time modulation ensures optimised current waveform in CCFF mode

• Frequency hopping near line zero-crossing

• Rapid line/load transient compensation (dynamic response enhancer)

• Valley turn-on

• High drive capability: −500 mA / +800 mA

• VCC voltage range: 9.5 V to 35 V

• Low start-up power consumption

• Version A: Low VCC start-up voltage (10.5 V), Version B: High VCC start-up voltage (17.0 V)

• Line voltage range detection

• Configurable for low harmonic content across wide input/load ranges

• Compliant with EN61000-3-2 Class C for dimmable ballasts across wide load ranges

• Lead-free packaged device

NCP1611ADR2G Specifications

Switching frequency:    20 kHz

Minimum operating temperature:    -40°C

Maximum operating temperature:    +125°C

Mounting Style:    SMD/SMT

Package / Case:    SOIC-8

Pd - Power Dissipation:    550 mW

NCP1611ADR2G Typical Applications

• Computer, television, and adapter power supplies

• LED drivers and ballasts (including dimmable models)

• All offline applications requiring power factor correction
