GD32F303RET6 is a high-performance 32-bit microcontroller featuring an ARM Cortex-M4 core operating at up to 120MHz, supporting double-precision floating-point operations and DSP instructions. It incorporates 512KB of Flash memory and 64KB of SRAM, capable of meeting the demands of diverse complex applications.

GD32F303RET6 Features

High-performance processor core: ARM Cortex-M4 core, 120MHz operating frequency, supporting double-precision floating-point operations and DSP instructions.

Extensive peripheral resources: Includes 51 GPIO ports, multiple 16-bit timers, 3 x 12-bit ADC units (16 channels total), 2 x 12-bit DAC units, 5 x USART interfaces, 2 x I²C interfaces, 3 x SPI interfaces, 1 x CAN 2.0B interface, and 1 x USB 2.0 FS interface.

High-efficiency power management: Offers multiple low-power operating modes, suitable for battery-powered applications.

High reliability and stability: Undergone rigorous testing and validation, delivering highly reliable operation with strong anti-interference capabilities.

Comprehensive development ecosystem: Provides ring communication libraries, standard peripheral libraries, and support for multiple development environments including Keil and IAR.

GD32F303RET6 Specifications

CPU Core: ARM Cortex-M4

CPU Clock Frequency: 120MHz

Operating Voltage: 2.6V to 3.6V

Memory Resources:

Flash Capacity: 512KB

SRAM Capacity: 64KB

Peripheral Interfaces:

GPIO Ports: 51

ADC Units: 3 units, 12-bit precision, 16 channels total

DAC Units: 2, 12-bit precision

PWM Resolution: 16-bit

Timers: 6 x 16-bit general-purpose timers

USART Interfaces: 5

I²C Interfaces: 2

SPI Interfaces: 3

CAN Interface: 1

USB Interface: Full-speed USB 2.0 device

Package Type: LQFP-64 (10x10mm)

Operating temperature range: -40°C to 85°C

Application Areas

The GD32F303RET6 is suitable for diverse fields, including but not limited to:

Industrial automation: Driving sensors and actuators, implementing data acquisition and processing.

Consumer electronics: Serving as a core control unit to coordinate and communicate between devices.

Automotive electronics: Enabling multiple control functions within vehicle systems.

Medical equipment: Providing precise monitoring and control capabilities.
