S25FS064SAGMFV013 Quad SPI flash memory is a high-performance and low-power storage solution and is widely used in various embedded systems, such as consumer electronic products like smart phones, tablet computers and digital cameras.

Features Of S25FS064SAGMFV013

• Serial peripheral interface (SPI) with multi-I/O

- SPI clock polarity and phase modes 0 and 3

- Double data rate (DDR) option

- Extended addressing: 24- or 32-bit address options

- Serial command subset and footprint compatible with S25FL1-K, S25FL-P and S25FL-S SPI families

- Multi I/O command subset and footprint compatible with S25FL1-K S25FL-P and S25FL-S SPI families

• Read

- Commands: Normal, Fast, Dual Output, Dual I/O, Quad Output, Quad I/O, DDR Quad I/O

- Modes: Burst Wrap, Continuous (XIP), QPI (QPI)

- Serial flash discoverable parameters (SFDP) and common flash interface (CFI), for configuration information.

• Program

- 256- or 512-bytes page programming buffer

- Program suspend and resume

- Automatic ECC -internal hardware error correction code (ECC) generation with single bit error correction

• Erase

- Hybrid sector option

• Physical set of eight 4 KB sectors and one 32 KB sector at the top or bottom of address space with all remaining sectors of 64 KB

- Uniform sector option

• Uniform 64 KB or 256 KB blocks for software compatibility with higher density and future devices

- Erase suspend and resume

- Erase status evaluation

• Cycling endurance

- 100,000 program-erase cycles, minimum

• Data retention

- 20 year data retention, minimum

• Security features

- One time program (OTP) array of 1024 bytes

- Block protection:

• Status register bits to control protection against program or erase of a contiguous range of sectors.

• Hardware and software control options

- Advanced sector protection (ASP)

• Individual sector protection controlled by boot code or password

• Option for password control of read access

• Technology

- 65-nm MIRRORBIT™ technology with ECLIPSE architecture

• Single supply voltage with CMOS I/O

- 1.7 V to 2.0 V

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
