USB83340AMR-B-V02 is specifically optimised for applications where low operating current and standby current are critical. This device integrates 3.3V and 1.8V voltage regulators, enabling operation from a single power supply.

USB83340AMR-B-V02 implements the ULPI interface using Microchip's package-free technology, enabling the physical layer to achieve low-latency transceiver functionality.

USB83340AMR-B-V02 Features

Designed, manufactured, tested, characterised, and certified for automotive applications

Service and Support

Compliant with USB-IF Battery Charging 1.1 specification

Supports Link Power Management (LPM)

Integrated electrostatic discharge protection circuitry

Virtually eliminates high-speed electrical performance degradation

Battery charging

Stereo and mono/microphone audio

USB Full-Speed/Low-Speed Data Transfer

All ULPI pins enter tri-state during sleep mode, placing the device in low-current state

1.8V to 3.3V Input/Output Voltage Range

Programmable USB Transceiver Drive Strength to restore signal integrity

Programmable USB Receiver Sensitivity

ULPI Clock Input Modes (60MHz supplied by link)

0 to 3.6V input drive tolerance

Accepts noisy clock sources as internal low-jitter PLL reference

Multi-frequency support

Crystal/resonator support

Intelligent detection circuit identifies USB charger, headset or cable insertion status

UART mode supports non-USB serial data transmission

5.0V internal short-circuit protection for ID/DP/DM lines to VBus® or ground

32-pin (5×5mm) lead-free QFN package, RoHS compliant

Automotive operating temperature range: -40°C to +105°C

Target Applications

The USB83340AMR-B-V02 is the preferred solution for automotive high-speed USB connectivity applications, particularly where minimising PCB space, power consumption and interface pins is essential.

• In-vehicle USB host implementation

• Test interfaces for in-vehicle entertainment systems

• Automotive integrated host units

• USB portable device charging

• Rear-seat entertainment system access

• Internal connection buses

• Isolation of high-value SoCs from external environments
