【AMPAK】AP6212 — WiFi + Bluetooth 4.0 + FM RX SIP Module, QFN-44

Product Details:

Model: AP6212

Package: QFN-44

Type: WiFi + Bluetooth 4.0 + FM RX SIP Module

Overview:

The AP6212 is a module with full WiFi and Bluetooth functionality. This highly integrated module enables a variety of applications, including web browsing, VoIP, and Bluetooth headphones.

Additionally, it features seamless roaming capabilities and advanced security, and can interact with 802.11b/g/n access points from different vendors in a wireless local area network. The wireless module complies with the IEEE 802.11 b/g/n standards, achieving a maximum speed of 72.2 Mbps in single-antenna transmission under the 802.11n specification, 54 Mbps as specified by IEEE 802.11g, or 11 Mbps as specified by IEEE 802.11b for connecting to a wireless local area network.

The AP6212 provides an SDIO interface for Wi-Fi and a UART/I2S/PCM interface for Bluetooth. This compact module combines Wi-Fi and Bluetooth technology, offering a comprehensive solution specifically designed for portable devices.

AP6212 Product Features:

802.11b/g/n single-band radio

Bluetooth V4.0 (HS), with an integrated Class 1.5 power amplifier, supporting low-power (BLE)

Simultaneous operation of Bluetooth, FM (RX) RDS/RBDS, and WLAN

Single-antenna simultaneous reception of BT/WLAN

WLAN host interface options: - SDIO v2.0 - Up to 50 MHz clock rate

BT host digital interface: - UART (up to 4 Mbps)

FM multiple audio routing options: I2S, PCM, eSCO, A2DP

IEEE coexistence technology integrated chip solution

ECI - Enhanced Coexistence Support, capable of coordinating WLAN reception around BT SCO transmissions
