STM32F103CBU6 (32-bit microcontroller - MCU) medium-density performance series product, featuring a high-performance Arm® Cortex®-M3 32-bit RISC core operating at 72 MHz.

Product details:

Model: STM32F103CBU6

Package: UFQFPN-48 (7x7)

Type: 32-bit microcontroller - MCU

Core processor: ARM® Cortex®-M3

Core specifications: 32-bit

Speed: 72 MHz

I/O Count: 37

Program Storage Capacity: 128KB (128K x 8)

RAM Size: 20K x 8

Voltage - Power Supply (Vcc/Vdd): 2V to 3.6V

Data Converter: A/D 10x12b

Operating Temperature: -40°C to 85°C (TA)

STM32F103CBU6 — Mainstream high-performance series Arm Cortex-M3 MCU with 128 KB Flash memory, 72 MHz CPU, motor control, USB, and CAN.

STM32F103CBU6 Product Features:

Arm® 32-bit Cortex®-M3 processor core

Maximum frequency 72 MHz, with performance of 1.25 DMIPS/MHz (Dhrystone 2.1) during 0 wait state memory accesses

Single-cycle multiplication and hardware division

Memory

64 or 128 kilobytes of Flash

20 kilobytes of SRAM

Clock, Reset, and Power Management

2.0 to 3.6 V application power supply and I/O

POR, PDR, and Programmable Voltage Detector (PVD)

4 to 16 MHz crystal oscillator

Internal 8 MHz factory-calibrated RC oscillator

Internal 40 kHz RC oscillator

CPU clock using PLL

Calibrated 32 kHz oscillator for RTC

Low power consumption

Sleep, stop, and standby modes

VBAT power supply for RTC and backup registers

2 12-bit, 1 µs A/D converters (up to 16 channels)
