The MX23A26NF1 is an automotive connector manufactured by JAE Electronics, part of the MX23A series. This connector features a 26-pin male pin design with a pitch of 2.5mm, suitable for a variety of applications.

MX23A26NF1 Technical Specifications

Connector Type: Connector

Contact Type: Male Pins

Pitch: 2.5mm (0.098 inches)

Number of Pins: 26

Number of Rows: 2

Row Spacing: 4.40mm (0.173 inches)

Mounting Type: Through-hole, Right-angle

Termination Type: Solder

Fastening Type: Latch Mount

Contact Material: Brass

Contact Surface Treatment: Tin

Insulation Material: Polybutylene Terephthalate (PBT), Glass-Fibre Reinforced

Operating Temperature Range: -40°C to +125°C

Rated Current: 3A

Insulation Resistance: 100 MOhms

Features: Board-to-Board, Waterproof

Application scenarios

MX23A26NF1 is widely used in the following fields:

Automotive electronics: Suitable for automotive electronic control units (ECUs), motorcycles, ships, etc.

Industrial equipment: Used in industrial automation equipment, PLC control cabinets, servo drives, etc.

Smart home: Suitable for smart home hubs, robot controllers, and other applications requiring high response speeds.
