CY14V101QS-BK108XQ is a 1 Mb (128 K × 8) four-wire SPI nvSRAM with an integrated high-reliability SONOS Flash unit that automatically saves SRAM data to non-volatile storage upon power loss and automatically restores it upon power-up. The device combines the unlimited read/write endurance of SRAM with the data retention capability of Flash, making it ideal for critical systems requiring high-speed write operations and absolute data integrity.

CY14V101QS-BK108XQ Specifications

• Storage Capacity: 1 Mbit (128 K × 8)

• Interface: SPI clock up to 108 MHz, supports Quad-SPI expansion

• Power supply: 2.7 V – 3.6 V single power supply

• Operating temperature: -40 °C to +105 °C (industrial/automotive grade)

• Package: 24-FBGA (8 mm × 6 mm, 1 mm pitch), surface mount

• Data retention: > 20 years at 85 °C

• Unlimited SRAM read/write cycles, over 1 million Flash erase/write cycles

CY14V101QS-BK108XQ Typical Applications

• Automotive ECUs, dashcams, battery management systems

• Industrial PLCs, servo drives, motion controllers

• Smart grids, electricity meters, concentrators

• Communication base stations, RAID controllers, data loggers
