The AD9826KRSZRL is a complete analogue signal processor designed for imaging applications. It features a three-channel architecture and is designed to sample and condition the output of a three-line colour CCD array. Each channel consists of an input clamping circuit, a correlated double sampler (CDS), an offset DAC, and a programmable gain amplifier (PGA), all connected via multiplexing to a high-performance 16-bit ADC.

AD9826KRSZRL Features

16-bit 15 MSPS analogue-to-digital converter

3-channel 16-bit operation, up to 15 MSPS

1-channel 16-bit operation, up to 12.5 MSPS

2-channel mode for mono sensors with odd-even outputs

Correlated double sampling

1–6 programmable gain

300 mV programmable offset

Input clamping circuit

Internal voltage reference

Multiplexed byte-width output

Optional single-byte output mode

3-wire serial digital interface

3 V/5 V digital I/O compatibility

28-pin SSOP package

Low-power CMOS: 400 mW (typical)

Supports standby mode

Applications of AD9826KRSZRL

Flatbed document scanners

Digital copiers

Multifunction peripheral devices

Infrared imaging applications

Machine vision
